The most versatile Dunlop wah pedal, designed for guitarists who need a wide range of options on stage.
- Bypassable booster
- Control to adjust the pedal frequency
- Dimebag Darell signature edition
Dimebag Darrell combined the swagger of a Cowboy with high-gain riffs loaded with harmonics. One of the most significant elements of his sound and dynamics was the Cry Baby Wah, and at a time when wah pedals had fallen out of fashion, Dime proudly waved his wah flag high. Armed with his experience and knowledge gained through years of touring, he helped design the most versatile wah created by Dunlop: The Dime Cry Baby from Hell Wah.
- Wah
- Dimebag Darrell Signature Cry Baby From Hell
- Extended sweep range
- Choose from 6 different frequency ranges
- Adjustable 'Tow Down' frequency
- Controllable and switchable boost (+17 dB max.)
- Volume, variable Q, and precise adjustment controls
- 6-way frequency range switch
- Boost switch
- Adjustable oscillating voltage
- Internal JP2 switch for two output modes ('pass through' / parallel mode)
- Status LED
- Metal enclosure
- 'Skateboard' style pedal board
- Finish: Black Camo
- Mono 6.3 mm input
- 2 mono 6.3 mm output jacks
- Power supply via 9V battery or optional 9V DC adapter (not included)
- Power input with 2.1 x 5.5 mm barrel connector with negative center
- Current consumption: 2.5 mA
- Dimensions (L x W x H): 250 x 100 x 94 mm
- Weight: 1.72 kg
About Jim Dunlop USA
Dunlop Manufacturing, Inc. is a musical accessories manufacturer specializing in effects pedals, based in Benicia, California, USA. Founded in 1965 by Scottish-American Jim Dunlop, the company evolved from a small home-based business into a major manufacturer of musical equipment. Since then, Dunlop has acquired several well-known effects pedal brands, such as Cry Baby, MXR, and Way Huge.
EAN13: 0710137116436
Data sheet
- Effects Loop
- No
- Power Supply
- Batteries & Adapter
- Format
- Expression Pedal
- Technology
- Analog
- True Bypass
- Yes
- Effect For
- Guitar
- Voltage
- 9V
- In
- Mono
- Out
- Mono
- Effect Type
- Wha-Wha
- Power Supply Included
- No
- USB Port
- No
- MIDI Control
- No
- EXP Out
- No
- SALIDA FOOTSWITCH
- No
- Tap Tempo
- No
