This edition features a reverse delay mode, with Swell and reverb, Tap tempo with subdivisions. It can be used in True bypass mode or Trails mode (allowing the effect’s tail to continue sounding after the pedal is switched off).

• Adjustable reverb with a PlateDelay-style tape tone, featuring Bucket Brigade Device (BBD) sensitivity
• Adjustable loop durations in Trails mode and auto-oscillation when holding down the Tap switch
• Expression pedal input
• EXP control to select the function of the expression pedal:
  • Decay: Controls the reverb tail length
  • R Mix: Controls the blend of reverb with the dry signal
  • Time: Removes time control from the interface and assigns it to the pedal, producing a drastically different effect than the pot
  • Repeats: Controls the number of delay repeats
  • D Mix: Controls the blend of delay with the original signal
  • Toggle: Removes the miniswitch so you can select the delay type via the expression pedal
• Ratio control: selects time subdivisions when using Tap tempo, including 1/1, 4/4, 2/3, ½, 1/3, and ¼
• The mini switch allows switching between delay modes: Normal, Reverse, and Sweep
• Soft-touch relay switches (requires power to operate)
• Operates on 9V
• Consumes 410mA
• Input impedance 1M Ohm
• Metal chassis
• 6.3mm mono jack input and output
• Dimensions: 118 x 105 x 57mm

About EarthQuaker Devices

EarthQuaker Devices was founded in 2004 by musician Jamie Stillman, who began designing effect pedals after successfully repairing a broken overdrive pedal. Today, the company is staffed by a team deeply dedicated to music. They handcraft and test each pedal individually in Ohio, USA.
